Engine Brand |
WEICHAI |
|
Model Number |
WP4.1D66E200 |
|
MOQ |
1 Set |
|
Payment Terms |
L/C , T/T |
|
Warranty |
18 months after shipment / 2000 hours of operation |
Weichai Diesel Generator Sets cover an ultra-wide power range of 16-3600KWM, compatible with 50/60Hz dual frequencies, supported by a full range of engines from WP2.3 to 16M55 With three configurations (open, sound-proof, containerized) and low fuel consumption of 2.3-87.5L/H, they meet diverse power needs from small backup, medium production to large infrastructure, guaranteed by Chinese power quality.
|
Place of Origin: |
China |
Certification: |
ISO, CE |
|
Genset Type: |
Open Frame/Soundproof |
Engine: |
WEICHAI |
|
Alternator: |
Farrand / Stamford / Leroy Somer |
Controller: |
Smartgen / Deepsea |
|
Starting Method: |
Electric |
Aspiration: |
Turbocharged |
|
Supply Ability: |
2000 sets per year |
|
|
|
Highlight:Trailer Mounted Diesel Generator,Trailer Mounted Diesel Generator 62kva,55kw diesel generator |
|||
|
Generator Set |
|
|
Genset model |
WP4.1 |
|
Genset rated power |
55KW/68KVA |
|
Rated voltage |
400/230V (adjustable) |
|
Frequency |
50 Hz |
|
Power factor |
0.8 Lagging |
|
Connecting type |
3 phase 4 wire |
|
Cooling system |
Closed cycle water-cooled with fan, water tank |
|
Overall dimension (L×W×H) mm |
1047× 678× 830 |
|
Gross weight (kg) |
400 |
|
Diesel Engine |
|
|
Brand |
WEICHAI |
|
Model |
WP4.1D66E200 |
|
Engine type |
12 cylinders in Vee,4 stroke, air-to-air after-cooled |
|
Aspiration |
Turbocharged |
|
Rotating speed |
1500 RPM |
|
Engine cooling system |
Water-cooled |
|
Speed governing system |
Electronic speed governor |
|
Starting method |
By 24V batteries |
|
Engine filter system |
Dry type air filter ,fuel filter, oil filter, water filter |
|
Displacement(L) |
4.087 |
|
Bore× Stroke |
105*118 |
|
Alternator |
|
|
Brand |
Leroy Somer |
|
Excite type |
Brushless self-excited AVR regulation |
|
Connecting type |
3 phase 4 pole |
|
Steady frequency change |
0.50% |
|
No load voltage |
≥95%-105% |
|
Steady voltage |
≤±1% |
|
Insulation class |
Class H |
|
Protection grade |
IP23 |
|
The components of the genset |
|
|
(1) Diesel engine; (2) Alternator; (3) Water tank & radiator assembly; (4) Control panel; (5) Base frame. |
|
Application Scenarios
|
|
 |
 |
| Construction Sites | Data Centers | Residential Backup Power |
 |
 |
 |
| Industrial Operation | Mining Power | Evens & Rentals |
