| Product Title | Mitsubishi Series(50Hz) |
| Brand Name | Mitsubishi |
| Frequency | 50HZ |
| Voltage | 400V |
| Power | 715-2750KVA |
| Fuel | Diesel |
| Type | Open/Sound-proof/Containerized |
| Output Type | Three Phase |
The Mitsubishi Series diesel generator sets are designed for 50Hz power standards, with a capacity range of 715KVA to 2750KVA, suitable for medium to large industrial and infrastructure continuous power needs. Equipped with Mitsubishi’s efficient diesel engines—including S6R2, S12R, and S16R models—they offer stable operation, compact design, and are available in open, soundproof, and containerized configurations. Known for high reliability, low fuel consumption, and long service life, the series is widely used in factories, mines, data centers, and major engineering projects.
| Genset Model (50HZ) |
Engine Model | ESP | PRP | Fuel Cons L/H(mm) |
Open type L*W*H(mm) |
Containerized/Sound-proof typeL*W*H(mm) | ||
| KVA | KW | KVA | KW | |||||
| M650D5 | S6R2-PTA-C | 715 | 572 | 650 | 520 | 104.2 | 3570*1500*2230 | 5000*1600*2545 |
| M750D5 | S6R2-PTAA-C | 825 | 660 | 750 | 600 | 127.5 | 4000*1690*2250 | 5685*1950*2545 |
| M1250D5 | S12R-PTA-C | 1400 | 1120 | 1250 | 1000 | 175.3 | 5000*2060*2200 | C20 |
| M1400D5 | S12R-PTA2-C | 1540 | 1232 | 1400 | 1120 | 199.4 | 5500*2270*2450 | C20H |
| M1500D5 | S12R-PTAA2-C | 1650 | 1320 | 1500 | 1200 | 230.6 | 5500*2270*2450 | C20H |
| M1750D5 | S16R-PTA-C | 1915 | 1532 | 1750 | 1400 | 268.8 | 5650*2200*2565 | C40H |
| M1875D5 | S16R-PTA2-C | 2100 | 1680 | 1875 | 1500 | 284.8 | 5800*2200*2565 | C40H |
| M2050D5 | S16R-PTAA2-C | 2250 | 1800 | 2050 | 1640 | 371.6 | 5800*2200*2565 | C40H |
| M2250D5 | S16R2-PTAW-C | 2500 | 2000 | 2250 | 1800 | 377.2 | 6000*2575*2560 | C40H |
| M650D5 | S6R2-PTA | 715 | 572 | 650 | 520 | 104.2 | 3570*1500*2230 | 5000*1600*2545 |
| M750D5 | S6R2-PTAA | 825 | 660 | 750 | 600 | 127.5 | 4000*1690*2250 | 5685*1950*2545 |
| M800D5 | S12A2-PTA2 | 880 | 704 | 800 | 640 | 132.5 | 4300*2050*2200 | 5810*2090*2275 |
| M1000D5 | S12H-PTA | 1100 | 880 | 1000 | 800 | 165.6 | 4300*2050*2200 | 5810*2090*2275 |
| M1250D5 | S12R-PTA | 1400 | 1120 | 1250 | 1000 | 175.3 | 5000*2060*2200 | C20 |
| M1400D5 | S12R-PTA2 | 1540 | 1232 | 1400 | 1120 | 199.4 | 5500*2270*2450 | C20H |
| M1500D5 | S12R-PTAA2 | 1650 | 1320 | 1500 | 1200 | 239.6 | 5500*2270*2450 | C20H |
| M1750D5 | S16R-PTA | 1915 | 1532 | 1750 | 1400 | 268.8 | 5650*2200*2565 | C40H |
| M1875D5 | S16R-PTA2 | 2100 | 1680 | 1875 | 1500 | 284.8 | 5800*2200*2565 | C40H |
| M2050D5 | S16R-PTAA2-Y1 | 2250 | 1800 | 2050 | 1640 | 371.6 | 5800*2200*2565 | C40H |
| M2250D5 | S16R2-PTAW | 2500 | 2000 | 2250 | 1800 | 377.2 | 6000*2575*2560 | C40H |
| M2250D5 | S16R2-PTAW-E | 2500 | 2000 | 2250 | 1800 | 378.5 | 6000*2575*2560 | C40H |
| M2500D5 | S16R2-PTAW2-E | 2750 | 2200 | 2500 | 2000 | 419.1 | 6000*2575*2560 | C40H |
