Engine Brand |
Cummins |
|
Model Number |
6ZTAA13-G4 |
|
MOQ |
1 Set |
|
Payment Terms |
L/C , T/T |
|
Warranty |
18 months after shipment / 2000 hours of operation |
Cummins as a leading independent engine manufacturer globally, Cummins boasts a wide power range, mature product technology, high reliability, good fuel economy, and suitability for long-term continuous operation. With its comprehensive global after-sales service network and ample spare parts supply, it is widely used in data centers, hospitals, factories, mines, ships, and infrastructure projects, making it a mainstream brand with balanced overall performance and high market recognition.
|
Place of Origin: |
China |
Certification: |
ISO, CE |
|
Genset Type: |
Soundproof |
Engine: |
Cummins |
|
Alternator: |
Farrand / Stamford / Leroy Somer |
Controller: |
Smartgen / Deepsea |
|
Starting Method: |
By Batteries |
Aspiration: |
Turbocharged |
|
Supply Ability: |
5000 sets per year |
|
|
|
Highlight:Rainproof Cummins Stamford Diesel Generator Cummins Stamford Diesel Generator 500Kva |
|||
|
Generator Set |
|
|
Genset model |
C500D5 |
|
Genset rated power |
500KVA/400KW |
|
Rated voltage |
400/230V (adjustable) |
|
Rated current |
1500 Amps |
|
Frequency |
50 Hz |
|
Power factor |
0.8 Lagging |
|
Connecting type |
3 phase 4 wire |
|
Cooling system |
Closed cycle water-cooled with fan, water tank |
|
Overall dimension (L×W×H) mm |
4785*1650*2547 |
|
Gross weight (kg) |
6000 |
|
Diesel Engine |
|
|
Brand |
Cummins |
|
Model |
6ZTAA13-G4 |
|
Engine type |
12 cylinders in Vee,4 stroke, air-to-air after-cooled |
|
Aspiration |
Turbocharged |
|
Rotating speed |
1500 RPM |
|
Engine cooling system |
Water-cooled |
|
Speed governing system |
Electronic speed governor |
|
Starting method |
By 24V batteries |
|
Engine filter system |
Dry type air filter ,fuel filter, oil filter, water filter |
|
Displacement(L) |
45.84 |
|
Bore×Stroke(mm) |
130*163 |
|
Compression ratio |
13.6: 1 |
|
Fuel consumption (g/kw.h) |
≤211 |
|
Lube capacity(L) |
177 |
|
Alternator |
|
|
Brand |
Farrand |
|
Model |
FLD634G |
|
Excite type |
Brushless self-excited AVR regulation |
|
Connecting type |
3 phase 4 pole |
|
Steady frequency change |
0.50% |
|
No load voltage |
≥95%-105% |
|
Steady voltage |
≤±1% |
|
Insulation class |
Class H |
|
Protection grade |
IP23 |
|
The components of the genset |
|
|
(1) Diesel engine; (2) Alternator; (3) Water tank & radiator assembly; (4) Control panel; (5) Base frame. |
|
Application Scenarios
|
|
 |
 |
| Construction Sites | Data Centers | Residential Backup Power |
 |
 |
 |
| Industrial Operation | Mining Power | Evens & Rentals |
